Hargnemisklemm UK240/2A, 1P (4poles) 35-240mm² 380/425A, paigaldusplaat, MaxPRO, hall Kood:
1914135
|
Saadavus:
küsi tarneaega
|
Kaal:
0.6 kg/tk
|
Maht:
0.001 m3/tk
|
|
|
|
|
Terminal Block Al/Cu 2x35-240mm², grey
 |
|
| Name: |
Terminal Block Al/Cu 2x35-240mm², grey |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
screw |
| Screw head: |
hexagon
|
| Colour: |
grey |
| Wire mm²: |
35-240 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
8 mm |
| Nominal Rated Current A: |
Cu 850 A, Al 760 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
26 Nm (35-120mm²), 40 Nm (150-240mm²) |
|
|
|
File description
|
File type
|
Download link
|
|
Declaration of Conformity
|
PDF
|
Download link
|
|
|
|
|
|
